S professional beam clamps and hand trolleys - 2000-15000 kg

Create your own review

EUR 375,00 Excl. tax

EUR 453,75 Incl. tax

Excl. Shipping costs

The S series provides professional beam clamps and hand trolleys for safe and efficient industrial use. Select the correct variant by capacity, operating range and unit weight.

In stock

3-4 days

Quantity

- +

Add to cart

Add to wishlist

Uitstekende kwaliteit
Laagste prijs garantie
Snelle levering
More information? Contact us about this product
Add to comparison list

Product description

S professional beam clamps and hand trolleys - 2000-15000 kg

The S series provides professional beam clamps and hand trolleys for safe and efficient industrial use. Select the correct variant by capacity, operating range and unit weight.

Key features

Fast installation on suitable steel profiles
Suitable as a suspension point or for load travel, depending on model
Safety factor and proof load according to the product specification
Check beam size, load direction and WLL before use

Technical specifications

Model	Capacity	Range	Weight	Article code
S1	2000 kg	76-190	4 kg	SB3502001
S2	3000 kg	76-190	5.1 kg	SB3502003
S2A	3000 kg	76-190	7.4 kg	SB3502005
S3	4000 kg	150-254	10.4 kg	SB3502007
S3X	5000 kg	76-190	9 kg	SB3502009
S3A	5000 kg	150-305	14.9 kg	SB3502011
S4	7000 kg	101-228	17.5 kg	SB3502012
S4S	6000 kg	203-457	18.8 kg	SB3502013
S4A	10000 kg	203-457	27.3 kg	SB3502015
S12	15000 kg	203-457	53.8 kg	SB3502017
S14	15000 kg	406-610	63 kg	SB3502019
Norm	EN 12100-1/2, EN 13155 / EN 13157, AS 4991, ASME B30.20 (as applicable)

Properties

Compact design: Compact design and low tare weight.
Easy mounting: Easy mounting.
Marking: According to standard, CE-marked.
Standard: EN 13157, EN 12100.

Delivery and quotation

SALESBRIDGES delivers throughout the Netherlands and across Europe. For technical advice, availability or an RFQ, contact [email protected] or +31 6 52883848.
