Sump Tray Type WM / WO For 200 Litre Drums
The sump tray type WM / WO is designed for safe storage of up to 4 x 200 litre drums, or 200 litre drums in combination with 60 litre drums, canisters, and small cans.
- Uitstekende kwaliteit
- Laagste prijs garantie
- Snelle levering
- More information? Contact us about this product
- Add to comparison list
Sump Tray Type WM / WO For 200 Litre Drums
Product Information
The sump tray type WM / WO is designed for safe storage of up to 4 x 200 litre drums, or 200 litre drums in combination with 60 litre drums, canisters, and small cans.
The tray is made from 3 mm steel sheet and has 100 mm ground clearance, making it suitable for use with a pallet truck or forklift truck. Every unit is tested for leakage and is suitable for flammable liquids and substances hazardous to the aquatic environment according to GHS categories.
The WM version is supplied with a galvanized grid with a load capacity of 1000 kg/m². The WO version is supplied without grid.
Key Features
- For storage of max. 4 x 200 litre drums
- Also suitable for combinations with 60 litre drums, canisters, and small cans
- Construction made of 3 mm steel sheet
- 100 mm ground clearance
- Suitable for pallet truck or forklift truck
- Every unit tested for leakage
- Suitable for flammable liquids GHS categories 1–3
- Suitable for hazardous to aquatic environment GHS categories 1–4
- WM: with galvanized grid
- WO: without grid
- Finish: galvanized
Technical Specifications
| Specification | Value |
|---|---|
| Product Type | Sump tray for drums |
| Type | WM / WO |
| Capacity | Max. 4 x 200 litre drums |
| Construction | 3 mm steel sheet |
| Ground Clearance | 100 mm |
| Handling | Pallet truck / forklift truck |
| WM Version | With galvanized grid |
| WO Version | Without grid |
| Grid Load Capacity | 1000 kg/m² |
| Retention Capacity | 243 – 444 litres |
| Weight | 51 – 101 kg |
| Suitable For | Flammable liquids and water-polluting substances |
| GHS Flammable Liquids | Categories 1–3 |
| GHS Aquatic Hazard | Categories 1–4 |
| Finish | Galvanized |
Available Variants
| Model | Max. 200 L Drums | Dimensions L x W x H mm | Retention Capacity | Weight |
|---|---|---|---|---|
| WM-2/200 | 2 | 1200 x 800 x 365 | 243 L | 69 kg |
| WM-4/200 | 4 | 1200 x 1200 x 290 | 255 L | 84 kg |
| WM-4/400 | 4 | 1200 x 1200 x 415 | 440 L | 101 kg |
| WO-2/200 | - | 1200 x 800 x 360 | 243 L | 51 kg |
| WO-4/200 | - | 1200 x 1200 x 285 | 255 L | 60 kg |
| WO-4/400 | - | 1200 x 1200 x 415 | 444 L | 76 kg |
Versions
| Type | Description |
|---|---|
| WM | With galvanized grid, load capacity 1000 kg/m² |
| WO | Without grid |
Delivery
Delivery in the Netherlands and Belgium and shipping across Europe via SALESBRIDGES.
Request A Quote Or More Information
Email: [email protected]
Phone / WhatsApp: +31 6 52883848
| Brand | Salesbridges |
| Article code | SBWM2200 |
| SKU | SBWM2200 |
