Lightweight framed formwork VARIECO

Tried and tested crane-independent manhandled framed system for foundations, walls and columns.

The lightweight framed formwork Varieco by Salesbridges B.V. is a complete system including accessories, which delivers perfect forming performance on construction sites without use of a crane. Sufficient load-bearing capacity and long service life of the Varieco system makes it an cost-effective solution.

Sufficient load-bearing capacity:

• 60 kN/m² pressure of fresh concrete up to 3.00 m;
• 40 kN/m² pressure of fresh concrete up to 4.50 m;
• Can be vertically stacked up to 4.50 m with use of one joint;
• High quality film faced plywood with thickness of 15 mm. Film weight 240 g/m².

Cost-effective:

• Manhandled formwork panels minimize use of a crane;
• High number of use cycles means lower follow- up expenses;
• Reduction of expenses by means of restoration and cleaning possibilities;
• Galvanized or powder-coated steel frames, for long service life;
• High quality of concrete surface minimizes finishing

Easy handling and planning:

• All the connectors and accessories are easily fixed into the slots and quickly tighten, consequently forming time is efficient and maximized;
• The ingeniously coordinated panel widths permit optimum adaptation to any

Safe use:

• Accessories such as - supporting struts, wall brackets etc. make for save and easier handling of the

Areas of use of the Varieco system:

• Wall formwork;
• Column formwork;
• Foundation
