Lightweight framed formwork VARIECO
Tried and tested crane-independent manhandled framed system for foundations, walls and columns.
The lightweight framed formwork Varieco by Salesbridges B.V. is a complete system including accessories, which delivers perfect forming performance on construction sites without use of a crane. Sufficient load-bearing capacity and long service life of the Varieco system makes it an cost-effective solution.
Sufficient load-bearing capacity:
- 60 kN/m² pressure of fresh concrete up to 3.00 m;
- 40 kN/m² pressure of fresh concrete up to 4.50 m;
- Can be vertically stacked up to 4.50 m with use of one joint;
- High quality film faced plywood with thickness of 15 mm. Film weight 240 g/m².
- Manhandled formwork panels minimize use of a crane;
- High number of use cycles means lower follow- up expenses;
- Reduction of expenses by means of restoration and cleaning possibilities;
- Galvanized or powder-coated steel frames, for long service life;
- High quality of concrete surface minimizes finishing
Easy handling and planning:
- All the connectors and accessories are easily fixed into the slots and quickly tighten, consequently forming time is efficient and maximized;
- The ingeniously coordinated panel widths permit optimum adaptation to any
- Accessories such as - supporting struts, wall brackets etc. make for save and easier handling of the
Areas of use of the Varieco system:
- Wall formwork;
- Column formwork;
