Hydraulic Mini Stacker 400kg – 1200mm Lift

Salesbridges

Hydraulic Mini Stacker 400kg – 1200mm Lift

EUR 900,00 Excl. tax

EUR 1.089,00 Incl. tax

Hydraulic mini stacker with fixed forks and loose chromed platform for half size pallets or as mobile lifting table. Manual foot pump with foldable lever for lifting and turning knob for lowering. Platform 650x580mm. Capacity 400kg. Lift 80-1200mm. Inner

In stock

1-2 weeks

Quantity

- +

Add to cart

Add to wishlist

Uitstekende kwaliteit
Laagste prijs garantie
Snelle levering
More information? Contact us about this product
Add to comparison list

Product description

Hydraulic Mini Stacker – 400 kg – 1200mm Lift

The hydraulic mini stacker is equipped with both fixed forks and a loose, chromed platform for multipurpose use. You can handle half size pallets and/or use it as a mobile lifting table. Manual stacker with foldable foot pump lever for lifting and manual turning knob for lowering.

Platform size (LxW): 650x580 mm. Inner measure between supporting legs: 370 mm. Platform in sheet metal is standard.

Key Features

Capacity: 400 kg
Load center: 300 mm
Lift height: 80-1200 mm
Fork length: 650 mm
Fork width (total/fork): 550/100 mm
Platform size: 650x580 mm
Inner measure between supporting legs: 370 mm
Manual foot pump operation
Foldable foot pump lever
Manual turning knob for lowering
Chromed platform included

Technical Specifications

Specification	SBST4001200
Type	Foot pump
Capacity (kg)	400
Load center (mm)	300
Lifting height min-max (mm)	80-1200
Lifting speed	12 mm/stroke
Fork width total/fork (mm)	550/100
Fork length (mm)	650
Steering wheel / Loading wheel (mm)	125x35/75x20
Fork wheel (mm)	Ø150
Turning radius (mm)	850
Dimensions (LxWxH) (mm)	1050x580x1300
Platform (LxW) (mm)	650x580
Inner measure between supporting legs (mm)	370
Weight (kg)	98
